HOGSTER ZAP 2.8 - 11.2x35mm Compact Thermal Scope (BE43355) Americas

100% aluminum alloy body

Superior predator control at medium-range distances up to 1000 yards

Replaceable 18350 batteries can be charged directly via the scope's USB-C port.

Picture-in-Picture function- 2X multiplied image on the top of the display

Automatic shutter based thermal 12uμ VOx 384x488 core with Auto- or Manual calibration

Switchable image polarity: White Hot / Black Hot / Red Hot / Iron Hot / Colored

6 reticle patterns

6 color options for each reticle pattern

Manual control of image sharpness, screen brightness, and image contrast

Ability to save 5 reticle settings

An internal focusing lens mechanism

5V DC external power supply option via the USB-C type port

Blind Pixel repair tool option

Standby mode

Digital Compass

Digital zoom rapid movement 2X, 3X, 4X

Inclinometer

Battery status indicator

Nitrogen purged

Video out

16Gb internal memory

Built-in internal recording function in .mp4 (video) and .jpeg (image) formats

Timer

Freeze Function for one shot zero

Picatinny mount

Hottest point tracker

4-year manufacturer’s transferable warranty on parts and labor

The all-new Bering Optics® HOGSTER ZAP™ Dedicated Medium-Range Compact Thermal scope features an advanced 12μm Vanadium Oxide 384x288 core and a high-quality 100% Germanium Lens, making it ideal for medium-range predator control. Superior optics combined with a precision internal focusing lens mechanism and proprietary electronics create the cutting-edge performance of the scope. HOGSTER ZAP™ features an intuitive, user-friendly menu to customize settings to the shooter’s needs without disengaging from the target, including BDC and Crosshair reticles.

There are picture-in-picture and zeroing calibration memory functions, digital compass and inclinometer to further enhance the user experience. The scope is rated for the .308 caliber and is equipped with a Picatinny rail. Its compact size allows it to be used as a handheld thermal imager for observation. An optional external 5VDC power supply can be connected via USB-C type port and cable (included). The scope is nitrogen-purged, water-resistant, dust- and shock-proof.

Optical Magnification, x	2.8x
Digital Magnification, x	2X, 3X, 4X
Objective lens system	35mmF/1.1
Angular FOV at Optical Magnification (horizontal x vertical), degrees	H 7.5° x V 5.7°
Linear FOV at Optical Magnification @ 100yrds/90m (Horizontal x Vertical), yd/m	H13.1 / 11.7 x V10 / 9
Eye relief, mm	40
Focus range, yard	4 to infinity
Diopter Adjustment, D	-4; +4
Core resolution, pxl	384x288
Pixel pitch, µm	12
Start-up time, min., sec.	10
Image refresh rate, Hz	50
Thermal Sensitivity (NETD), mK	≤35
Display type and resolution, pxl	OLED 1440x1080
Detection Range, yd (Target size: Running Hog L16 & H19), approx., yd/m	990 / 900
Dimensions, in/mm	7.87”x2.6”x2.83” / 200x66x73
Weight without mount and batteries, but with eyepiece and lens cap, oz/g	23.3 / 660
Power supply	3.7V 18350 rechargeable (two) or 5V DC
Estimated battery life, hours	5 with two 3.7V 18350 2800mAh
Operating temperature, typical, °F	-4°F to +122°F
Water intrusion	IP66
Humidity, %/°С	up to 96%

HOGSTER ZAP™ 2.8-11.2x35mm, 12uµ VOx 384x288 Thermal Weapon Sight
Picatinny Mount with 2 mounting screws
4mm hex key
Front lens protective cap
Rubber eye guard
2pcs of 3.7V 18350 1400mAh rechargeable batteries
Batteries charger and cable
Power Adapter 5V DC output
Video-out or external power supply Type C USB cable
1pc Self-Heated target
Carrying Case
Lens Cleaning Cloth
Instruction Manual
