SUPER YOTER-R 3.0-12.0x50mm

Thermal scopes
> SUPER YOTER R 3.0-12.0x50mm Compact Thermal Weapon Sight, VOx 640X480 core resolution, 12 µm pixel pitch with the LaRue Tactical® QD mount (BE46050L)

Features

Superior for predator control at medium and long-range distances

Excellent performer in high humidity conditions
Picture-in-Picture function- 2X multiplied image on a top of the display
Automatic shatter based thermal VOx core with Auto- or Manual calibration
Switchable image polarity: White Hot / Black Hot / Red Hot / Colored Hot
8 reticle patterns including 3 BDC reticles
4 color options for each reticle pattern
Precise W/E adjustment increments is 0.54” at 1X (3.0x native magnification) and just 0.14” at 4X multiplied image
Manual control of the image sharpness and screen brightness
Manual control of the contrast
Manual control of the image background balance of white (Cool or Warm)
Ability to save 4 profiles of zeroing calibration data
Stradiametric Rangefinder function to estimate the distance to the targets; Manually adjustable target’s height
A precise lens focusing mechanism
5V DC external power supply option via a Type-C USB port
Blind Pixel repair tool

Standby mode

Digital Compass
Inclinometer
Battery status indicator
Nitrogen purged
Video out
32Gb internal memory
Built-in internal recording function in .mp4 (video) and .jpeg (image) formats
Wi-Fi capable- allows media recording to the mobile device (iOS or Android App is required)
Equipped with the LaRue Tactical® Quick-Detach (QD) lockable mount
4 years warranty




Customer review

Thank you also for a great product , as I live in South Georgia and our heat and humidity can cripple most thermals but the SUPER YOTER always out-performs the so call competition and I am out there shooting permits for farmers every night this time of year. We have engaged deer out to 600 yards but usually shoot 100-450 yards.
Clint

First year hunting at night, we had a lot of fun. Never had any issues with the Super Yoter and the picture quality is amazing.
Thanks guy
Brady


About

The Bering Optics SUPER YOTER R 3.0-12.0x50mm Compact Thermal Weapon Sight features the advanced 12µm Vanadium Oxide (VOx) 640x480 core resolution with 50Hz refresh rate that makes the scope ideal for predator control at medium- and long-range distances. This thermal Scope has an optical magnification of 3.0x and digital zoom of 2X, 3X, 4X.

The scope comes with a reliable low profile Quick-Detach LaRue Tactical® lockable mount and is Wi-Fi capable that allows media recording to mobile device (with required iOS or Android App).

The wide range of controls and capabilities allow the user to adapt the scope to various conditions and personal preferences. There are 8 reticle patterns including 3 BDC reticles, along with four color options for each reticle pattern. The sight operation is controlled with three buttons allowing easy selection of the options. A unique adjustable stradiametric rangefinder can be set to the height of the animals, thus increasing the overall usefulness of this feature. Other useful features of the Super Yoter R are a wide selection of the image adjustment options as well as the image background adjustment and calibration.

The precise W/E adjustment increments is 0.54” at the 1X (native magnification of 3.0x) and the zero-increment change based on the zoom level is only 0.14” at the 4X digital magnification level. This provides a valuable advance in accuracy for a Thermal Scope.

Specifications
Optical Magnification, x

3.0x

Digital Magnification, x

2X, 3X, 4X

Objective lens system

50mmF/1.0

Angular FOV at Optical Magnification (Horizontal x Vertical), degrees

H8.5° x V6.4°

Linear FOV at Optical Magnification @ 100yrds/90m (Horizontal x Vertical), yd/m

H15 / 13.7 x V11.2 / 10.2

Eye relief, mm

46.6

Focus range, yard

0.8 to infinity

Diopter Adjustment, D

-5; +5

Reticle W/E adjustment increments per pxl

0.54” at 1X (3.0x magnification)
0.14” at 4X multiplication

Core resolution, pxl

640 x 480

Pixel pitch, µm

12

Start-up time, min., sec.

20

Image refresh rate, Hz

50

Thermal Sensitivity (NETD), mK

<40

Display type and resolution, pxl

OLED 1024x768

Detection Range, (6 ft tall target), approx., yd/m

2200 / 2000

Dimensions, in/mm

8.46”x3.15”x2.36” / 215x80x60

Weight w/out batteries, but with QD mount, eye cup & lens cover, oz/g

20 / 570

Power supply

3V CR123 (two) or
3.7V rechargeable (two)
or 5V DC (USB C-type)

Estimated battery life, hours

3.5 from two 3V CR123

Operating temperature, typical, °F

-14°F to +122°F

Water intrusion/°С

IP66

Humidity, %

up to 96%

In Box
  • SUPER YOTER R Thermal Weapon Sight
  • Quick-Detach (QD) lockable mount
  • Front lens protective cap
  • Rubber eye guard
  • 2 CR123 batteries
  • L-shaped Video-out Type-C USB cable with 3.5mm RCA male connector plug
  • Soft Carrying Case with a shoulder strap
  • Lens Cleaning Cloth
  • Instruction manual
